aston martin cygnet (2012) rear lights parts diagram

17.0301.01 - Rear Lights

Aston Martin Cygnet (2012) Rear Lights Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: AY2Y-13404-CA
          LAMP ASSEMBLY, REAR, RHD, RH
          With Obscuration Band
          from £1,657.94
          from £1,657.94
          FENDER LMP ASY RH OBS Genuine Aston Martin - New (to order)
          # 1
          MPN: AY2Y-13405-CA
          LAMP ASSEMBLY, REAR, RHD, LH
          With Obscuration Band
          from £1,657.94
          from £1,657.94
          FENDER LMP ASY LH OBS Genuine Aston Martin - New (to order)
          # 1
          MPN: AY2Y-13404-DA
          LAMP ASSEMBLY, REAR, LHD, RH
          With Obscuration Band
          from £1,543.33
          from £1,543.33
          FENDER LMP ASY RH OBS Genuine Aston Martin - New (to order)
          # 1
          MPN: AY2Y-13405-DA
          LAMP ASSEMBLY, REAR, LHD, LH
          With Obscuration Band
          from £1,657.94
          from £1,657.94
          FENDER LMP ASY LH OBS Genuine Aston Martin - New (to order)
          # 2
          MPN: 90179-05102
          NUT, REAR LAMP
          3 per Assembly
          from £1.42
          from £1.42
          REAR LAMP FIXING NUT Genuine Aston Martin - New (to order)
          # 3
          MPN: AY2Y-13A538-AA
          PANEL INSERT, LAMP ASSEMBLY, REAR, RH
          from £124.99
          from £124.99
          REAR LAMP INFILL RH Genuine Aston Martin - New (to order)
          # 3
          MPN: AY2Y-13A539-AA
          PANEL INSERT, LAMP ASSEMBLY, REAR, LH
          from £124.99
          from £124.99
          REAR LAMP INFILL LH Genuine Aston Martin - New (to order)
          # 4
          MPN: AY2Y-138452-BA
          LAMP ASSEMBLY, DUMMY FINISHER, RH
          With Obscuration Band
          from £443.76
          from £443.76
          DUMMY REAR LAMP RH OBS Genuine Aston Martin - New (to order)
          # 4
          MPN: AY2Y-138453-BA
          LAMP ASSEMBLY, DUMMY FINISHER, LH
          With Obscuration Band
          from £443.76
          from £443.76
          DUMMY REAR LAMP LH OBS Genuine Aston Martin - New (to order)
          # 5
          MPN: AY2Y-13A4-AA
          Gasket, Lamp Assembly, Rear
          Gasket, Lamp Assembly, Rear Genuine Aston Martin - New (to order)
          # 6
          MPN: 703266
          SCREW M6X10 PANHEAD
          2 per Assembly
          from £0.47
          from £0.47
          SCREWM6X10 PAN HEAD Genuine Aston Martin - New (to order)
          # 7
          MPN: 81496-60010
          CLIP, LAMP ASSEMBLY, REAR, GUIDE
          1 per Assembly
          from £1.08
          from £1.08
          GUIDE Genuine Aston Martin - New (to order)
          # 8
          MPN: 81558-74010
          BRACKET, WITH TAPPING, RHS
          from £13.76
          from £13.76
          REAR LAMP BRACKET RH/LH Genuine Aston Martin - New (to order)
          # 8
          MPN: 81568-74010
          BRACKET, WITH TAPPING, LHS
          from £8.75
          from £8.75
          REAR LAMP BRACKET RH/LH Genuine Aston Martin - New (to order)
          # 9
          MPN: AY2Y-112358-AA
          DECAL, TAILGATE INNER, RH
          from £2.34
          from £2.34
          DECAL T/GATE RH Genuine Aston Martin - New (to order)
          # 9
          MPN: AY2Y-112359-AA
          DECAL, TAILGATE INNER, LH
          from £2.34
          from £2.34
          DECAL T/GATE LH Genuine Aston Martin - New (to order)
