ferrari f430 spider (rhd) fuel system pumps and pipes parts diagram

0009 - fuel system pumps and pipes

Ferrari F430 Spider (RHD) FUEL SYSTEM PUMPS AND PIPES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 001
            MPN: 180477
            COMPLETE RH FUEL PUMP
            -No longer supplied- -Replaced by 239811-
            Supersession
            Supersession
            Genuine Ferrari Part (no longer available to order)
            # 001
            MPN: 239811
            COMPLETE RH FUEL PUMP
            from £199.12
            from £199.12
            This part replaces part number 180477
            RH COMPLETE FUEL PUMP Genuine Ferrari Part - New In stock
            RH COMPLETE FUEL PUMP Original Equipment - New In stock
            # 002
            MPN: 195841
            LH FUEL PUMP AND COMPLETE FUEL LEVEL INDICATOR MECHANISM
            -No longer supplied- -Replaced by 239812-
            Supersession
            Supersession
            This part replaces part number 193725
            Genuine Ferrari Part (no longer available to order)
            # 002
            MPN: 239812
            LH FUEL PUMP AND COMPLETE FUEL LEVEL INDICATOR MECHANISM
            from £207.76
            from £207.76
            This part replaces part number 195841
            LH COMPLETE FUEL PUMP AND FUEL LEVEL Genuine Ferrari Part - New In stock
            LH COMPLETE FUEL PUMP AND FUEL LEVEL COMPLETE Eurospares Approved Part - New In stock
            # 003
            MPN: 196124
            FUEL SENSOR
            from £110.27
            from £110.27
            FUEL LEVEL INDICATOR Genuine Ferrari Part - New (to order)
            # 005
            MPN: 181681
            GASKET
            from £11.53
            from £11.53
            gasket. Genuine Ferrari Part - New (to order)
            PUMP FASTENING RING NUT GASKET Genuine Maserati Part - New In stock
            # 006
            MPN: 213720
            RH CONNECTOR PIPE
            from £156.60
            from £156.60
            RH DELIVERY FUEL PIPE Genuine Ferrari Part - New (to order)
            # 007
            MPN: 213719
            LH CONNECTOR PIPE
            from £98.81
            from £98.81
            LH DELIVERY FUEL PIPE Genuine Ferrari Part - New In stock
            LH DELIVERY FUEL PIPE Genuine Ferrari Part - Used In stock
