031 - Gearbox Lay Shaft
Ferrari F50 Gearbox Lay Shaft Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 000
MPN: 169544
COMPLETE CROWN WHEEL AND PINION R.10/37
- Not as spare part now - Replace by 169792
Supersession
Supersession
This part replaces part number 156070 - and 1 more. Click to view details
# 000
MPN: 169792
COMPLETE CROWN WHEEL AND PINION R.10/37
from £2,562.78
from £2,562.78
This part replaces part number 169544
# 001
MPN: 168091
OUTPUT SHAFT
- Not as spare part now - With the complete crown wheel and pinion 169792
# 001
MPN: 168139
OUTPUT SHAFT
- Not as spare part now - With the complete crown wheel and pinion 169544
# 002
MPN: 10269850
THREADED PLUG
from £0.94
from £0.94
# 003
MPN: 101636
BEARING
from £94.79
from £94.79
# 004
MPN: 156376
BAG FOR BEARINGS
from £97.22
from £97.22
# 005
MPN: 146715
SPACER
- Th. mm. 2,0
from £50.01
from £50.01
# 005
MPN: 151278
SPACER
- Th. mm. 1,6 - Possible fitting
from £50.01
from £50.01
# 005
MPN: 151279
SPACER
- Th. mm.1,8 - Possible fitting
from £50.01
from £50.01
# 005
MPN: 151280
SPACER
- Th. mm. 2,2 - Possible fitting
from £50.01
from £50.01
# 005
MPN: 151281
SPACER
- Th. mm. 2,4 - Possible fitting
from £71.45
from £71.45
# 006
MPN: 146716
SPACER
- Th. mm. 3,5
from £83.38
from £83.38
# 007
MPN: 122152
SPACER
from £131.97
from £131.97
# 007
MPN: 138136
SPACER
- As an alternative
from £11.03
from £11.03
# 008
MPN: 121822
BEARING
from £215.71
from £215.71
# 009
MPN: 127496
WASHER
from £0.47
from £0.47
This part replaces part number 10516671 - and 2 more. Click to view details
# 010
MPN: 16044021
SCREW
from £1.70
from £1.70
This part replaces part number 119631
# 011
MPN: 156894
CARRIER BUSH
from £44.07
from £44.07
# 012
MPN: 166969
PINION FOR 2ND GEAR
from £283.11
from £283.11
# 013
MPN: 101604
ROLLER CAGE
from £72.10
from £72.10
# 014
MPN: 152193
INNER RING
- Valid till stock exhaustion
Supersession
Supersession
# 014
MPN: 169780
INNER RING
- Valid after stock exhaustion of 152193
from £48.11
from £48.11
This part replaces part number 152193
# 015
MPN: 152194
SYNCHRONIZER MIDDLING RING
- Valid till stock exhaustion
Supersession
Supersession
# 015
MPN: 169779
SYNCHRONIZER MIDDLING RING
- Valid after stock exhaustion of 152194
from £45.19
from £45.19
This part replaces part number 152194
# 016
MPN: 152191
SYNCHRONIZER RING
from £118.97
from £118.97
# 017
MPN: 152189
SLEEVE
from £76.95
from £76.95
# 018
MPN: 154439
SYNCHRONIZER BODY
from £187.25
from £187.25
# 019
MPN: 152195
SMALL BLOCK
from £0.47
from £0.47
# 020
MPN: 152197
BALL
from £2.09
from £2.09
# 021
MPN: 152196
SPRING
from £0.47
from £0.47
# 022
MPN: 166967
PINION FOR 1ST GEAR
from £351.12
from £351.12
# 023
MPN: 101604
ROLLER CAGE
from £72.10
from £72.10
# 024
MPN: 104704
ROLLER CAGE RACE
from £359.61
from £359.61
# 025
MPN: 156895
SPACER
from £36.67
from £36.67
# 026
MPN: 156224
PINION FOR 6TH GEAR
from £135.56
from £135.56
# 027
MPN: 150810
TRANSMITTING DISC
from £178.38
from £178.38
# 028
MPN: 166880
PINION FOR 5TH GEAR
from £829.01
from £829.01
# 029
MPN: 166974
PINION FOR 4TH GEAR
from £145.72
from £145.72
# 030
MPN: 166973
PINION FOR 3TH GEAR
from £1,569.75
from £1,569.75
# 031
MPN: 159193
ROLLER CAGE
from £30.45
from £30.45
# 032
MPN: 156948
ROLLER CAGE RACE
from £37.26
from £37.26
# 033
MPN: 166880
PINION FOR 5TH GEAR
from £829.01
from £829.01
# 034
MPN: 152479
SYNCHRONIZER RING
from £149.72
from £149.72
# 035
MPN: 152206
SLEEVE
from £42.34
from £42.34
# 036
MPN: 154475
SYNCHRONIZER BODY
from £75.76
from £75.76
# 037
MPN: 152195
SMALL BLOCK
from £0.47
from £0.47
# 038
MPN: 152197
BALL
from £2.09
from £2.09
# 039
MPN: 152196
SPRING
from £0.47
from £0.47
# 040
MPN: 156655
LOCK RING
from £0.68
from £0.68
# 041
MPN: 156980
RING NUT
from £20.79
from £20.79
# 042
MPN: 156975
BUSHING
from £9.18
from £9.18
# 043
MPN: 101031
GASKET
from £0.94
from £0.94
# 044
MPN: 157010
THREADED BUSHING
from £5.34
from £5.34
# 045
MPN: 14159470
FLEXIBLE PIN
from £2.81
from £2.81
# 046
MPN: 157009
BUSHING
from £4.48
from £4.48
# 047
MPN: 10569273
WASHER
Supersession
Supersession
# 048
MPN: 14305224
SCREW
from £0.47
from £0.47
# 049
MPN: 228055
BEARING
from £45.99
from £45.99
This part replaces part number 131056 - and 1 more. Click to view details
# 050
MPN: 108656
BEARING
from £309.40
from £309.40
This part replaces part number 104257
# 051
MPN: 151135
SPACER
from £19.81
from £19.81
