lamborghini lp610-4 spyder (2017) shock absorber rear parts diagram

511.01.00 - SHOCK ABSORBER REAR

Lamborghini LP610-4 SPYDER (2017) SHOCK ABSORBER REAR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 001
        -
        WHEEL BEARING HOUSING
        SEE ILLUSTRATION : 505.01-REAR
        # 002
        MPN: 4T0512019R
        Shock Absorbers
        std
        from £1,861.36
        from £1,861.36
        SHOCK ABSORBER SPYDER Genuine Lamborghini - New (to order)
        # 002
        MPN: 4T7512019C
        Shock Absorbers
        MAGNETIC RIDE
        from £1,786.74
        from £1,786.74
        SHOCK ABSORBER MAGNA RIDE LIFT Genuine Lamborghini - New (to order)
        # 003
        MPN: 4S0505465A
        COUPLING ROD
        from £60.40
        from £60.40
        COUPLING ROD MSS Genuine Lamborghini - New In stock
        COUPLING ROD MSS Genuine Lamborghini - Used In stock
        # 004
        MPN: 4S0511409
        ANTI-ROLL BAR
        from £133.16
        from £133.16
        STABILIZER MSS Genuine Lamborghini - New In stock
        STABILIZER MSS Genuine Lamborghini - Used In stock
        # 005
        MPN: 4E0803171B
        THREADED PLATE
        M12X1,5-M12X1,5
        from £7.23
        from £7.23
        THREADED TUBE Genuine Lamborghini - New (to order)
        # 006
        MPN: N10784702
        HEXAGON FLANGE SCREW
        AM12X1,5X85-M12X1.5X85
        from £3.38
        from £3.38
        HEXAGON FLANGE M12X1.5X85 Genuine Lamborghini - New In stock
        HEXAGON FLANGE SCREW Genuine Porsche Part - New (to order)
        # 007
        MPN: N10106402
        HEXAGON COLLAR NUT SELF-LOCKING
        M12X1,5-M12X1,5
        from £1.34
        from £1.34
        PREV.TORQUE TYPE M12X1.5 Genuine Lamborghini - New In stock
        SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
        # 008
        MPN: N10689301
        SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
        M8X25
        from £1.58
        from £1.58
        12-POINT SOCKET M8X25 Genuine Lamborghini - New In stock
        BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
        # 009
        MPN: N10272302
        HEXAGON COLLAR NUT SELF-LOCKING
        M10-M10
        from £1.32
        from £1.32
        PREV.TORQUE TYPE M10 Genuine Lamborghini - New In stock
        SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
        # 010
        MPN: N10425302
        HEX COLLARED BOLT
        M10X62X45-M10X62X45
        from £3.68
        from £3.68
        HEXAGON FLANGE M10X62X45 Genuine Lamborghini - New (to order)
        Genuine Porsche Part (no longer available to order)
        # 011
        MPN: 4S0512041
        HEXAGON FLANGE SCREW
        M12X1, 5X175X90-M12X1.5X175X90
        from £8.51
        from £8.51
        FASTENING ELEMENT BM12X1,5X175X90 TC Genuine Lamborghini - New (to order)
        # 012
        MPN: 7L5971847B
        CABLE TIE WITH TERMINAL SOCKET
        from £1.90
        from £1.90
        CABLE CLAMP 193.00X1.00-45.00 Genuine Lamborghini - New In stock
