maserati 2.24v ignition system - accesories parts diagram

020 - Ignition System - Accesories

Maserati 2.24v Ignition System - Accesories Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                          #
                                                          Part number
                                                          Description
                                                          Key
                                                          Price
                                                          # 001
                                                          MPN: 313737125
                                                          AIR MODULATING SOLENOID VALVE
                                                          Maserati PART 313737125 Genuine Maserati Part - New (to order)
                                                          # 002
                                                          MPN: 313720324
                                                          RING
                                                          from £1.07
                                                          from £1.07
                                                          SEAL RING VAE Genuine Maserati Part - New (to order)
                                                          # 003
                                                          MPN: 313720325
                                                          RING
                                                          from £2.29
                                                          from £2.29
                                                          SEAL RING VAE Genuine Maserati Part - New (to order)
                                                          # 004
                                                          MPN: 311053394
                                                          SCREW
                                                          Supersession
                                                          Supersession
                                                          Genuine Maserati Part (no longer available to order)
                                                          # 006
                                                          MPN: 313753329
                                                          SOLENOID VALVE FASTENING FLANGE
                                                          Maserati PART 313753329 Genuine Maserati Part - New (to order)
                                                          # 007
                                                          MPN: 312220411
                                                          FLAT WASHER
                                                          from £0.47
                                                          from £0.47
                                                          ROSETTA Genuine Maserati Part - New (to order)
                                                          # 008
                                                          MPN: 470079700
                                                          AIR TEMPERATURE SENSOR
                                                          from £70.65
                                                          from £70.65
                                                          AIR TEMPERATURE SENSOR ATS 0 Genuine Maserati Part - New (to order)
                                                          # 009
                                                          MPN: 313720118
                                                          ABSOLUTE PRESSURE SENSOR
                                                          Supersession
                                                          Supersession
                                                          Genuine Maserati Part (no longer available to order)
                                                          # 010
                                                          MPN: 312020510
                                                          UNION SCREW
                                                          from £2.63
                                                          from £2.63
                                                          This part replaces part number 193520 - and 1 more. Click to view details
                                                          UNION SCREW 12X1.25 Genuine Maserati Part - New (to order)
                                                          UNION SCREW 12X1.25 Genuine Maserati Part - Used In stock
                                                          # 013
                                                          MPN: 319237525
                                                          CORRUGATED PIPE
                                                          from £1.59
                                                          from £1.59
                                                          PIPE Genuine Maserati Part - New (to order)
                                                          # 014
                                                          MPN: 312050310
                                                          CLAMP
                                                          from £1.07
                                                          from £1.07
                                                          CLICK CLAMP 55080 Genuine Maserati Part - New (to order)
                                                          # 015
                                                          MPN: 312020506
                                                          SLEEVE
                                                          from £2.15
                                                          from £2.15
                                                          SLEEVE Genuine Maserati Part - New (to order)
                                                          # 016
                                                          MPN: 312053496
                                                          GASOLINE DELIVERY RH PIPE
                                                          from £3.86
                                                          from £3.86
                                                          Maserati PART 312053496 Genuine Maserati Part - New (to order)
                                                          # 017
                                                          MPN: 585064500
                                                          UNION
                                                          from £62.09
                                                          from £62.09
                                                          This part replaces part number 578064500
                                                          RACCORDO FILETTATO A 90 Genuine Maserati Part - New (to order)
                                                          # 018
                                                          MPN: 312237118
                                                          CLAMP
                                                          from £1.90
                                                          from £1.90
                                                          CLAMP Genuine Maserati Part - New (to order)
                                                          # 019
                                                          MPN: 312053500
                                                          SLEEVE
                                                          from £3.94
                                                          from £3.94
                                                          PIPE Genuine Maserati Part - New (to order)
                                                          # 020
                                                          MPN: 319253140
                                                          PRESSURE ADJUSTER
                                                          Maserati PART 319253140 Genuine Maserati Part - New (to order)
                                                          # 022
                                                          MPN: 14453381
                                                          RUBBER
                                                          from £0.70
                                                          from £0.70
                                                          O-RING D. 15.60X1 Genuine Maserati Part - New In stock
                                                          O.R.GASKET. Genuine Ferrari Part - New In stock
                                                          # 023
                                                          MPN: 312053485
                                                          SLEEVE
                                                          SLEEVE Genuine Maserati Part - New (to order)
                                                          # 024
                                                          MPN: 313720313
                                                          INJECTOR STOP SPRING
                                                          Maserati PART 313720313 Genuine Maserati Part - New (to order)
                                                          # 025
                                                          MPN: 312053497
                                                          GASOLINE DELIVERY LH PIPE
                                                          from £4.08
                                                          from £4.08
                                                          Maserati PART 312053497 Genuine Maserati Part - New (to order)
                                                          # 026
                                                          MPN: 313720121
                                                          INJECTOR
                                                          from £83.17
                                                          from £83.17
                                                          This part replaces part number 313720119
                                                          INJECTOR Genuine Maserati Part - New (to order)
                                                          # 027
                                                          MPN: 313720321
                                                          RING
                                                          from £2.82
                                                          from £2.82
                                                          SEAL RING Genuine Maserati Part - New (to order)
                                                          # 028
                                                          MPN: 585064500
                                                          UNION
                                                          from £62.09
                                                          from £62.09
                                                          This part replaces part number 578064500
                                                          RACCORDO FILETTATO A 90 Genuine Maserati Part - New (to order)
