017 - Oil Pump & Linkage
Ferrari 275 GTB/GTS 2 cam Oil Pump & Linkage Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: P 2
THREADED STUD
8 x 75
Supersession
Supersession
# 002
MPN: 520685
BEARING HOLDER
from £104.23
from £104.23
# 003
MPN: P 2
THREADED STUD
8x22
Supersession
Supersession
# 004
MPN: 520649
Corpo pompa olio
from £154.14
from £154.14
# 005
MPN: P1
THREADED STUD
6 x 32
Supersession
Supersession
# 006
MPN: 8R 5
WASHER
Supersession
Supersession
# 007
MPN: D 2
NUT
8
# 008
MPN: 520675
BOCCOLINA
from £54.66
from £54.66
# 009
MPN: 520674
DRIVEN GEAR
563
# 010
MPN: 520673
DRIVING GEAR
563
from £84.01
from £84.01
# 011
MPN: T F 4
PLUG
10 x 8
# 012
MPN: 520650
COVER
563
from £140.96
from £140.96
# 013
MPN: 12601279
WASHER
from £0.54
from £0.54
This part replaces part number 12601271 - and 2 more. Click to view details
# 014
MPN: D 3
NUT
6
# 015
MPN: 5 x 12
SCREW
2VR
# 016
MPN: P 2
THREADED STUD
8x60
Supersession
Supersession
# 017
MPN: P1
THREADED STUD
6x18
Supersession
Supersession
# 018
MPN: 95403254
INTERRUTTORE
from £135.23
from £135.23
This part replaces part number 103324
# 018
MPN: 95403254
INTERRUTTORE
from £135.23
from £135.23
This part replaces part number 103324
# 019
MPN: 10 R 2
WASHER
# 020
MPN: 55670
PIVOT
508 E
from £55.02
from £55.02
# 021
MPN: 520682
ASTA COMANDO 1ª E RM
563
from £191.55
from £191.55
# 022
MPN: 520149
SELECTOR FORK 1ª - REVERSE AND 4ª - 5ª SPEED
563
from £318.87
from £318.87
# 023
MPN: 103587
PLATE
from £5.85
from £5.85
This part replaces part number 92692 - and 1 more. Click to view details
# 024
MPN: B9
BOLT
6x20
# 025
MPN: 520150
SELECTOR FORK 2ª and 3ª SPEED
563
from £318.87
from £318.87
# 026
MPN: 93231
BOLT
from £7.23
from £7.23
# 027
MPN: 520680
SELECTOR FORK 4TH & 5TH GEARS
from £869.89
from £869.89
# 028
MPN: 520683
ASTA 2ª E 3ª VEL.
563
from £135.35
from £135.35
# 029
MPN: B9
BOLT
6x20
# 030
MPN: 520679
FORK 1ª AND REVERSE.
563
from £512.72
from £512.72
# 031
MPN: B F 1
CENTERING DOWEL
5
# 032
MPN: 520542
SCATOLA CAMBIO
563
from £380.24
from £380.24
# 033
MPN: 520565
PUNTALINO
563
from £10.05
from £10.05
# 034
MPN: 520567
SPRING
563
from £3.47
from £3.47
# 035
MPN: 520569
FONDELLO
563
# 036
MPN: AA 20 i
SEEGER RING
OEB
# 037
MPN: 100748
CENTRAL ROD ROLLER
342
from £22.36
from £22.36
This part replaces part number 53126
# 038
MPN: 520146
SIDE ROLLER ROLLER
563
Supersession
Supersession
# 039
MPN: 520544
PIVOT JOINT
563
# 040
MPN: 5201895/S
JOINT TERMINAL
563
# 041
MPN: 520190
INDEMOVABLE SHIFT CONTROL BAR ASSEMBLY
563
# 042
MPN: B1
BOLT
6x25
# 043
MPN: 520188/D
JOINT TERMINAL
563
# 044
MPN: 93770
PIN
from £1.22
from £1.22
# 045
MPN: 103189
GIUNTO
from £91.02
from £91.02
This part replaces part number 524508 - and 1 more. Click to view details
# 046
MPN: 520183
ALBERO PER LEVA
563
from £113.85
from £113.85
# 047
MPN: 103587
PLATE
from £5.85
from £5.85
This part replaces part number 92692 - and 1 more. Click to view details
# 048
MPN: 520148
SELECTOR FORK 2ND & 3RD GEARS
from £994.59
from £994.59
# 049
MPN: B9
BOLT
6x20
# 050
MPN: 520684
ASTA 3ª E 4ª VEL.
563
from £130.41
from £130.41
# 051
MPN: 520651
GASKET
563
from £27.44
from £27.44
# 052
MPN: 520647
COVER
563
from £275.97
from £275.97
# 053
MPN: D 3
NUT
6
# 054
MPN: 12601279
WASHER
from £0.54
from £0.54
This part replaces part number 12601271 - and 2 more. Click to view details
# 055
MPN: 520396
GEAR KNOB
(Chrome Type)
from £53.97
from £53.97
This part replaces part number 53630
# 055
MPN: 520396/L
GEAR KNOB
(Black Alloy Type) Not plastic type.
from £168.80
from £168.80
# 056
MPN: 53203
LOCKNUT
342
from £119.54
from £119.54
# 057
MPN: 520457
SELETTORE
563
# 058
MPN: AA 15e
SEEGER RING
OEB
Supersession
Supersession
# 059
MPN: 520566
SCODELLINO
563
from £2.10
from £2.10
# 060
MPN: 520568
SPRING
563
Supersession
Supersession
# 061
MPN: 520698
LEVER
563
# 062
MPN: IDS UNI209
NUT
LOBO 80
# 063
MPN: 127496
WASHER
from £0.54
from £0.54
This part replaces part number 10516671 - and 2 more. Click to view details
# 064
MPN: 127446
SEDE SFERICA
from £8.19
from £8.19
This part replaces part number 104316 - and 3 more. Click to view details
# 065
MPN: G C 1
DOWEL
8
# 066
MPN: 520543
COVER
563
# 067
MPN: P1
THREADED STUD
8x45
Supersession
Supersession
# 068
MPN: 1 D 8-UNI 209
NUT
LOBO 80
# 069
MPN: 127496
WASHER
from £0.54
from £0.54
This part replaces part number 10516671 - and 2 more. Click to view details
# 070
MPN: 6R4 1 D6
WASHER
LOBO
# 071
MPN: UNI 205
NUT
50
# 072
MPN: 520166
LEVER
563
from £104.40
from £104.40
# 073
MPN: 104282
PLUG
563
from £48.88
from £48.88
This part replaces part number 520162 - and 1 more. Click to view details
# 074
MPN: 520161
GASKET
563
Supersession
Supersession
