6.4A - Windscreen Wipers
Aston Martin V8 Virage (1999) Windscreen Wipers Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# -
MPN: 37-64583
Windscreen wiper linkage assembly
RHD
from £490.27
from £490.27
# -
MPN: 37-64584
Windscreen wiper linkage assembly
LHD
from £466.96
from £466.96
# 1
MPN: 37-54082
MOUNTING BRACKET
RHD
# 1
MPN: 37-54083
MOUNTING BRACKET
LHD
# 2
MPN: 37-52709
LEVER ASSEMBLY, MOTOR DRIVE
from £110.80
from £110.80
# 3
MPN: 37-52705
DRIVE LINK ASSEMBLY, WIPER MOTOR
from £60.86
from £60.86
# 3
MPN: 37-52707
DRIVE LINK, WIPER MOTOR
# 4
MPN: 695768
SPHERICAL BEARING, RH THREAD
from £17.27
from £17.27
# 5
MPN: 695769
SPHERICAL BEARING, LH THREAD
from £16.14
from £16.14
# 6
MPN: 692482
NUT, M8, RH THREAD
from £0.76
from £0.76
# 7
MPN: 695770
NUT, M8, LH THREAD
# 8
MPN: 37-53929
LEVER ASSEMBLY, PASSENGER'S SIDE
from £173.84
from £173.84
# 9
MPN: 37-52704
DRIVE LINK ASSEMBLY
from £60.86
from £60.86
# 9
MPN: 37-52706
DRIVE LINK
# 10
MPN: 695768
SPHERICAL BEARING, RH THREAD
from £17.27
from £17.27
# 11
MPN: 695769
SPHERICAL BEARING, LH THREAD
from £16.14
from £16.14
# 12
MPN: 692482
NUT, M8, RH THREAD
from £0.76
from £0.76
# 13
MPN: 695770
NUT, M8, LH THREAD
# 14
MPN: 37-54076
LEVER ASSEMBLY, DRIVER'S SIDE
from £145.99
from £145.99
# 15
MPN: 37-54046
MOUNTING BRACKET, WIPER MOTOR
from £218.53
from £218.53
# 16
MPN: 695774
CIRCLIP
from £0.86
from £0.86
# 17
MPN: 695775
CIRCLIP
from £6.06
from £6.06
# 18
MPN: 695776
BEARING
from £18.18
from £18.18
# 19
MPN: 695777
SHIM
from £0.73
from £0.73
# 20
MPN: 37-55321
RING NUT
from £32.44
from £32.44
# 21
MPN: 695778
WASHER
from £4.18
from £4.18
# 22
MPN: 695779
RUBBER WASHER
from £1.66
from £1.66
# 23
MPN: 692067
WASHER, SHAKEPROOF, M8
from £0.47
from £0.47
# 24
MPN: 695780
NUT, M8
from £0.47
from £0.47
# 24
MPN: 696647
NUT AND WASHER ASSY, M8
Repl items 23/24 january 1994
from £0.47
from £0.47
# 25
MPN: 37-55352
wiper motor
from £530.30
from £530.30
# 25
MPN: 37-64040
wiper motor
Volante from app (V) 60043
from £595.61
from £595.61
# 25
MPN: 37-74077
wiper motor
Volante from May 1995
from £467.30
from £467.30
# -
-
WASHER, SPRF, M8
# -
-
NUT, M8, BLACK
# 26
MPN: 695563
BOLT, M6 X 16
# 27
MPN: 695526
NUT, M6
from £0.47
from £0.47
# 28
MPN: 692077
NUT, M8
Motor bracket attach
# 29
MPN: 692047
WASHER, SPRING, M8
Motor bracket attach
from £0.47
from £0.47
# -
-
NUT, NYLOC, M8
# 30
MPN: 37-54144
WIPER ARM, DRIVERS SIDE RHD
Virage. Volante up to (V) 60045
# 30
MPN: 37-54145
WIPER ARM, DRIVERS SIDE LHD
+ (V) 60048 Virage. Volante up to (V) 60045
# 31
MPN: 37-54154
WIPER ARM, PASSENGERS SIDE
Virage. Volante up to (V) 60045
# 32
MPN: 37-52721
WIPER BLADE, 21
Virage. Volante up to (V) 60045
# -
-
WIPER ARM, DRIVERS SIDE RHD
# -
-
WIPER ARM, DRIVERS SIDE LHD
# -
-
WIPER ARM, PASSENGERS SIDE
# -
-
WIPER BLADE, 21 RHD
# -
-
WIPER BLADE, 21 LHD
# 33
MPN: 37-53252
HEAD COVER, WIPER ARM ENDS
from £6.05
from £6.05
# -
-
RUBBER SEAL, WIPER SPINDLE
