maserati qtp. (2011) 4.7 auto parking sensors parts diagram

097 - parking sensors

Maserati QTP. (2011) 4.7 auto Parking Sensors Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Price
                                # 01
                                MPN: 239082
                                PARKING SENSOR
                                from £54.35
                                from £54.35
                                # 02
                                MPN: 81458600
                                RING VALID FOR CARS WITH DARK PAINT
                                from £13.39
                                from £13.39
                                # 02
                                MPN: 81544800
                                RING VALID FOR CARS WITH LIGHT PAINT
                                from £4.31
                                from £4.31
                                # 03
                                MPN: 80371200
                                PARKING SENSOR SUPPORT
                                from £5.02
                                from £5.02
                                # 04
                                MPN: 239083
                                PARKING SENSOR
                                from £103.74
                                from £103.74
                                # 05
                                MPN: 80380200
                                RING
                                from £1.52
                                from £1.52
                                # 06
                                -
                                LH PARKING SENSOR SUPPORT
                                # 06
                                -
                                RH PARKING SENSOR SUPPORT
                                # 07
                                MPN: 16082401
                                SCREW
                                from £0.47
                                from £0.47
                                # 08
                                MPN: 245221
                                FRONT BUMPER CABLE
                                from £502.65
                                from £502.65
                                # 09
                                MPN: 239082
                                PARKING SENSOR
                                from £54.35
                                from £54.35
                                # 10
                                MPN: 80380200
                                RING VALID FOR CARS WITH DARK PAINT
                                from £1.52
                                from £1.52
                                # 10
                                MPN: 80380300
                                RING VALID FOR CARS WITH LIGHT PAINT
                                from £12.94
                                from £12.94
                                # 11
                                MPN: 80371300
                                PARKING SENSOR SUPPORT CENTRAL
                                from £5.02
                                from £5.02
                                # 11
                                MPN: 80371800
                                PARKING SENSOR SUPPORT LATERAL
                                from £12.86
                                from £12.86
                                # 12
                                MPN: 235148
                                REAR BUMPER CABLE
                                from £522.24
                                from £522.24
                                # 13
                                MPN: 223469
                                PARKING SENSOR BUZZER QUANTITY 2 FOR CARS WITH OPT. REAR AND FRONT PARKING SENSORS
                                from £14.54
                                from £14.54
                                This part replaces part number 184928 - and 1 more. Click to view details
                                # 13
                                MPN: 223469
                                PARKING SENSOR BUZZER QUANTITY 2 FOR CARS WITH OPT. REAR AND FRONT PARKING SENSORS
                                from £14.54
                                from £14.54
                                This part replaces part number 184928 - and 1 more. Click to view details
                                # 14
                                MPN: 285371
                                SENSORS PARKING CONTROL UNIT
                                Supersession
                                Supersession
                                This part replaces part number 284877
                                # 15
                                MPN: 14059114
                                NUT
                                from £0.54
                                from £0.54
