0027 - PTU REPAIR KIT

Ferrari FF (Europe) PTU REPAIR KIT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Price
            # 001
            MPN: 299391
            POSITION SENSOR KIT
            -Position sensor Q.ty 1- -TCEI M4X12 screw Q.ty 2- -Split washer Q.ty 2-
            from £608.07
            from £608.07
            # 002
            MPN: 299392
            ON/OFF VALVE KIT
            -On/off valve Q.ty 1- -TCEI M5X10 screw Q.ty 2- -Split washer Q.ty 2-
            from £289.67
            from £289.67
            # 003
            MPN: 299393
            COMPLETE HYDRAULIC SYSTEM KIT
            -Compl. hydraulic system Q.ty 1- -TCEI M6X90 screw Q.ty 4- -Corrugated spring washer Q.ty 4- -Flat split washer Q.ty 4- -O-ring Q.ty 6- -Rubber ring Q.ty 3- -Cable tie Q.ty 6-
            from £6,623.68
            from £6,623.68
            # 004
            MPN: 299394
            HYDRAULIC SYSTEM RIGID OIL PIPES KIT
            -Activation pipe 2/4 Q.ty 2- -Oil pipe Q.ty 2- -Bracket with sheath Q.ty 7- -Bracket with sheath Q.ty 1- -TCEI M6X14 screw Q.ty 3- -Washer Q.ty 3- -Nut Q.ty 3-
            from £798.47
            from £798.47
            # 005
            MPN: 299395
            COMPLETE PTU WIRING HARNESS KIT
            -PTU complete wiring harness PTU Q.ty 1- -Cable tie Q.ty 2- -Bracket with sheath d. 8 Q.ty 2- -Bracket with sheath d. 12 Q.ty 1-
            from £1,536.99
            from £1,536.99
            # 006
            MPN: 299396
            OIL LEVEL PLUG KIT
            -Compl. oil level cap Q.ty 1- -Seal gasket Q.ty 1- -Tapered threaded cap Q.ty 1-
            from £221.41
            from £221.41
            # 007
            MPN: 299397
            MAGNETIC PLUG KIT
            -Magnetic cap Q.ty 1- -Gasket Q.ty 1-
            from £21.27
            from £21.27
            # 008
            MPN: 299398
            RPM SENSOR KIT
            -Electromagnetic sensor Q.ty 1- -TCEI M6X14 screw Q.ty 1- -Tapered washer Q.ty 1- -Cable tie Q.ty 1-
            from £111.63
            from £111.63
            # 009
            MPN: 299399
            FASTENER COVER GASKET KIT ON REVERSE DRIVE SHAFT
            -O-ring Q.ty 1- -TSEI M5X10 screw Q.ty 3-
            from £2.18
            from £2.18
            # 010
            MPN: 299400
            PINION SEAT FASTENER COVER GASKET KIT ON COVER
            -Seeger ring Q.ty 1- -O-ring Q.ty 1-
            from £13.52
            from £13.52
            # 011
            MPN: 299401
            FRONT COVER ON PRIMARY SHAFT GASKET KIT
            -O-ring Q.ty 1- -TCEI M6X12 screw Q.ty 4-
            from £4.80
            from £4.80
            # 012
            MPN: 299402
            FASTENER COVER GASKET KIT ON REVERSE SECONDARY DRIVE SHAFT
            -O-ring Q.ty 1- -Seeger ring Q.ty 1-
            from £0.65
            from £0.65
            # 013
            MPN: 299403
            FASTENER COVER ON DRIVE SHAFT 2A/4A DRIVE GASKET KIT
            -O-ring Q.ty 1- -Seeger ring Q.ty 1-
            from £0.95
            from £0.95
            # 014
            MPN: 278333
            OIL TANK KIT
            -Clip Q.ty 1- -M6X20 screw Q.ty 2- -Oil reservoir Q.ty 1-
            from £151.34
            from £151.34
            # 015
            MPN: 278334
            LOW PRESSURE PIPE KIT
            -Low pressure pipe Q.ty 1- -Clip Q.ty 1- -Clip Q.ty 1-
            from £183.76
            from £183.76
            # 016
            MPN: 278335
            HIGH PRESSURE PIPE KIT
            -High pressure pipe Q.ty 1- -Connector Q.ty 2-
            from £297.27
            from £297.27
            # 017
            MPN: 278336
            PROPORTIONAL PRESSURE SOLENOID VALVE KIT
            -Solenoid valve Q.ty 1- -M4X12 screw Q.ty 2- -O-ring Q.ty 1-
            from £485.00
            from £485.00
            # 018
            MPN: 278337
            QUANTITATIVE PRESSURE SOLENOID VALVE KIT
            -Solenoid valve Q.ty 1- -M4X12 screw Q.ty 2- -O-ring Q.ty 1-
            from £472.00
            from £472.00
            # 019
            MPN: 278338
            POWER UNIT KIT
            -Compl. power unit Q.ty 1- -Connector Q.ty 1- -Clip Q.ty 1-
            from £1,801.59
            from £1,801.59
            # 020
            MPN: 262017
            CLUTCH PRESSURE SENSOR
            from £103.13
            from £103.13
            # 021
            MPN: 247296
            LINE PRESSURE SENSOR
            Supersession
            Supersession
            # 022
            MPN: 261836
            TEMPERATURE SENSOR
            from £21.32
            from £21.32
            # 023
            MPN: 262031
            ACCUMULATOR
            -Including O-ring, clamp and cap-
            from £216.91
            from £216.91
            # 024
            MPN: 261833
            FASTENER CAP ON DRIVE SHAFT 2A/4A DRIVE
            -O-ring not included-
            from £468.42
            from £468.42
            # 025
            MPN: 260813
            FASTENER COVER
            -O-ring not included-
            from £562.10
            from £562.10
            # 026
            MPN: 271776
            FASTENER COVER
            -O-ring not included-
            from £792.69
            from £792.69
            # 027
            MPN: 274396
            FRONT COVER ON PRIMARY SHAFT
            -O-ring not included-
            from £151.34
            from £151.34
            # 028
            MPN: 261411
            SAFETY VALVE
            from £230.60
            from £230.60
            # 029
            MPN: 265419
            PINION SEAT FASTENER COVER ON COVER
            -O-ring not included-
            from £461.21
            from £461.21
            # 030
            MPN: 152954
            BLEED SCREW
            from £3.26
            from £3.26
